Description
Dell Precision 7710
A full-size 17.3-inch mobile workstation with a workstation-grade Xeon processor, up to 64GB of RAM and NVIDIA graphics.
- Intel Xeon E3-1505M v5
- Max 64GB DDR4 (4 Slots)
- NVIDIA / AMD GPU
- FHD or 4K UHD
- Triple M.2/SATA Storage
- Processor Xeon E3-1505M v5, 4 Cores
- Max Memory 64GB DDR4, ECC-capable
- Graphics NVIDIA / AMD GPU
- Display 17.3" FHD or 4K UHD
The Dell Precision 7710 is an imported full-size mobile workstation built around the Intel Xeon E3-1505M v5, a workstation-class quad-core processor that supports ECC memory for extra data reliability. Four SODIMM slots take up to 64GB of DDR4, and the chassis supports up to three storage drives across two M.2 PCIe slots plus a shared M.2 PCIe/2.5-inch SATA bay. Graphics vary by unit, with an NVIDIA / AMD GPU and a 17.3-inch FHD or 4K UHD display option.
Why Choose the Precision 7710
- Workstation-Grade XeonThe E3-1505M v5 is a quad-core, 8-thread Xeon that boosts up to 3.7GHz and supports ECC memory for mission-critical workloads.
- Up to 64GB DDR4Four SODIMM slots take 4x16GB, so memory is upgradable and not soldered.
- Triple Storage BaysTwo dedicated M.2 PCIe slots plus a shared M.2/2.5-inch SATA bay support up to three drives for large project files and OS/data separation.
- Professional GraphicsDedicated NVIDIA / AMD GPU, certified for professional CAD, 3D and rendering software.
- 4K UHD Display OptionThe UHD panel runs at 400 nits for bright, detailed visual work.
- Full-Size ServiceabilityA larger 17.3-inch chassis leaves room for maximum expansion and easier component servicing over the machine's life.
In real work, the E3-1505M v5 with a large memory pool handles AutoCAD and Revit models, SolidWorks assemblies and multi-layer Photoshop files, while ECC memory support adds reliability for workstations running long simulation or rendering jobs. On units with a Quadro M4000M or M5000M you can also run heavier GPU rendering and demanding 3D viewports, and the extra storage bays give you room for OS, scratch disk and project archives separately.
Some honest limits. Every unit is a different configuration, so check the variant for exact RAM, storage, graphics and display before you buy. This is a 2016-era Skylake platform, so it is well behind current CPUs in raw multi-core speed. The 7710 is one of the larger and heavier mobile workstations Dell has made, at around 3.42kg with a substantial power adapter, so it suits desks and travel bags more than daily commuting. Thunderbolt 3 was an optional configuration on this chassis, not standard, so confirm it is present on your specific unit if needed.
Who It's Built For
- Engineers & ArchitectsRun CAD, BIM and simulation software with a strong Quadro card, ECC memory support and lots of RAM.
- Designers & EditorsEdit large image and video files on the optional 4K UHD display with fast multi-drive storage.
- Technical & Data TeamsTake advantage of ECC-capable memory for workloads where data integrity matters.
- Budget-Conscious ProfessionalsGet certified Quadro graphics and a large memory ceiling at a lower entry cost than current-generation models.
| Processor | Intel Xeon E3-1505M v5, 4 Cores, 8 Threads, 2.8GHz base, up to 3.7GHz, 8MB Cache, 45W, ECC-capable |
|---|---|
| Graphics Options | NVIDIA Quadro M3000M 4GB GDDR5, Quadro M4000M 4GB GDDR5, Quadro M5000M 8GB GDDR5, AMD FirePro W5170M 2GB GDDR5, FirePro W7170M 4GB GDDR5 |
| Max Memory | 64GB DDR4 2133/2667MHz, ECC or non-ECC (4x SODIMM Slots, 4x16GB) |
| Storage | Up to 2x M.2 PCIe NVMe SSD plus 1x shared M.2 PCIe/2.5-inch SATA bay (up to 3 drives total) |
| Display Options | 17.3-inch FHD (1920x1080) or UHD 4K (3840x2160), 400 nits on UHD panel |
| Ports | 4x USB 3.0 with PowerShare, Mini DisplayPort, HDMI, headphone/mic combo jack, SD card reader, optional Thunderbolt 3 |
| Weight | Approx. 3.42kg (7.55lbs) and up, varies by configuration |
